Name: Teammachine SLR 02 DISC ONE
Brand: BMC
SKU: BMC-18a-000100-s0470
Availability: OutOfStock

[{"id":47388669116736,"title":"47","option1":"47","option2":null,"option3":null,"sku":"BMC-18a-000100-s0470","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Teammachine SLR 02 DISC ONE - 47","public_title":"47","options":["47"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":47388669149504,"title":"51","option1":"51","option2":null,"option3":null,"sku":"BMC-18a-000100-s0510","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Teammachine SLR 02 DISC ONE - 51","public_title":"51","options":["51"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":47388669182272,"title":"54","option1":"54","option2":null,"option3":null,"sku":"BMC-18a-000100-s0540","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Teammachine SLR 02 DISC ONE - 54","public_title":"54","options":["54"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":47388669247808,"title":"56","option1":"56","option2":null,"option3":null,"sku":"BMC-18a-000100-s0560","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Teammachine SLR 02 DISC ONE - 56","public_title":"56","options":["56"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":47388669313344,"title":"58","option1":"58","option2":null,"option3":null,"sku":"BMC-18a-000100-s0580","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Teammachine SLR 02 DISC ONE - 58","public_title":"58","options":["58"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":47388669378880,"title":"61","option1":"61","option2":null,"option3":null,"sku":"BMC-18a-000100-s0610","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Teammachine SLR 02 DISC ONE - 61","public_title":"61","options":["61"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

Technische Übersicht

Rahmenset

Rahmen:
Teammachine SLR02 - Disc-specific | ACE Technology - 02 Carbon

Gabel:
ACE Technology | 02 Carbon

Cockpit

Lenker:
BMC RAB 02 | ergo top shape | compact bend

Vorbau:
BMC RSM01 | w/ computer and camera mount

Sattelstütze:
Teammachine SLR02 "D" Carbon | 15mm offset

Sattel:
Fizik Antares R7 | manganese

Sattel

Sattelstütze:
Teammachine SLR02 "D" Carbon | 15mm offset

Sattel:
Fizik Antares R7 | manganese

Antrieb

Übersetzung:
2 x 11

Kurbel:
Shimano Ultegra | 52-36T

Kassette:
Shimano Ultegra | 11-30T

Kette:
Shimano Ultegra

Umwerfer:
Shimano Ultegra Di2

Schaltwerk:
Shimano Ultegra Di2

Schalthebel:
Shimano Ultegra Di2 | Hydraulic

Bremsen

Bremshebel:
Shimano Ultegra Di2 | SM-RT800 Rotors (160/140

Räder

Felgen:
DT Swiss P1850 SPLINE db 23

Naben (V/H):
DT Swiss P1850 SPLINE db 23 | Thru Axle (12mm)

Bereifung:
Vittoria Rubino Pro | 25mm

Weitere Informationen

Produktsicherheitsverordnung (GPSR):
Sicherheitshinweise GPSR (EU)
Verantwortliche Person gemäss GPSR (EU)

Size	47	51	54	56	58	61
Reach	367	377	386	392	401	409
Stack	506	530	550	565	584	608
Bar Drop	123	123	123	123	123	123
Bar Reach	77	77	77	77	77	77
Bar Width	400	420	420	420	440	440
BB Drop	69	69	69	69	69	69
Crank Length	170	170	172.5	172.5	172.5	175
Fork Length	365	365	365	365	365	365
Fork Rake	41.6	41.6	41.6	41.6	41.6	41.6
Front Center	570	575	587	596	611	627
Head Tube	113	133	153	168	188	213
Head Tube Angle	70.5	72	72.5	72.5	72.5	72.5
Rear Center	410	410	410	410	410	410
Seat Angle	73.5	73.5	73.5	73.5	73.5	73.5
Seat Tube	423	468	513	534	554	584
Seatpost Length	300	300	300	300	300	300
Seatpost Offset	15	15	15	15	15	15
Stem Angle	+/- 8	+/- 8	+/- 8	+/- 8	+/- 8	+/- 8
Stem Length	90	100	110	120	120	120
Top Tube	517	535	550	560	575	590
Trail	76	66	63	63	63	63
Wheelbase	970	975	986	996	1012	1027
