Name: Roadmachine 02 ONE
Brand: BMC
SKU: BMC-19a-000026-s0470
Availability: OutOfStock

Roadmachine 02 ONE | BMC | bikes | Road, Road | Endurance

STEALTH

BMC Archive Product

Kompatible Teile und Zubehör

Di2 Kit - No 7

CAD 54.00 Produkt anzeigen

Di2 Plug Kit - No 5

CAD 54.00 Produkt anzeigen

Expander - No 4

CAD 26.00 Produkt anzeigen

Handlebar RCB01

CAD 418.00 Produkt anzeigen

Roadmachine Chainguide

CAD 20.00 Produkt anzeigen

Roadmachine FD Hanger

CAD 54.00 Produkt anzeigen

Roadmachine Seat Tube Seal

CAD 20.00 Produkt anzeigen

[{"id":47388982706496,"title":"47","option1":"47","option2":null,"option3":null,"sku":"BMC-19a-000026-s0470","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Roadmachine 02 ONE - 47","public_title":"47","options":["47"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":47388983853376,"title":"51","option1":"51","option2":null,"option3":null,"sku":"BMC-19a-000026-s0510","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Roadmachine 02 ONE - 51","public_title":"51","options":["51"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":47388983886144,"title":"54","option1":"54","option2":null,"option3":null,"sku":"BMC-19a-000026-s0540","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Roadmachine 02 ONE - 54","public_title":"54","options":["54"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":47388983918912,"title":"56","option1":"56","option2":null,"option3":null,"sku":"BMC-19a-000026-s0560","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Roadmachine 02 ONE - 56","public_title":"56","options":["56"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":47388984082752,"title":"58","option1":"58","option2":null,"option3":null,"sku":"BMC-19a-000026-s0580","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Roadmachine 02 ONE - 58","public_title":"58","options":["58"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":47388984115520,"title":"61","option1":"61","option2":null,"option3":null,"sku":"BMC-19a-000026-s0610","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Roadmachine 02 ONE - 61","public_title":"61","options":["61"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

Technische Übersicht

Rahmenset

Rahmen:

Gabel:

Cockpit

Lenker:

Vorbau:

Sattelstütze:

Sattel:

Sattel

Sattelstütze:

Sattel:

Antrieb

Übersetzung:

Kurbel:

Kassette:

Kette:

Umwerfer:

Schaltwerk:

Schalthebel:

Bremsen

Bremshebel:

Räder

Felgen:

Naben (V/H):
DT Swiss E1800 SPLINE db 32 | Thru Axle (12mm)

Bereifung:
Vittoria Rubino Pro | 28mm

Weitere Informationen

Produktsicherheitsverordnung (GPSR):
Sicherheitshinweise GPSR (EU)
Verantwortliche Person gemäss GPSR (EU)

Size	47	51	54	56	58	61
Reach	375 / 369	378 / 372	387 / 382	393 / 388	400 / 395	407 / 402
Stack	514 / 530	539 / 555	560 / 576	574 / 590	593 / 609	617 / 633
Bar Drop	125	125	125	125	125	125
Bar Reach	70	70	70	70	70	70
Bar Width	400	420	420	420	440	440
BB Drop	71	71	71	71	71	71
Crank Length	170	170	172.5	172.5	175	175
Fork Length	369	369	369	369	369	369
Fork Rake	50	50	45	45	45	45
Front Center	583.7	595	597	608	622	636
Head Tube	95	122	138	154	173	198
Head Tube Angle	71.2	71.2	72	72	72	72
Rear Center	410	410	410	410	410	410
Seat Angle	74.2	74.2	74.2	74.2	74.2	74.2
Seat Tube	420	464	507	522	539	573
Seatpost Length	250	250	310	310	310	310
Seatpost Offset	15	15	15	15	15	15
Stem Angle	±8	±8	±8	±8	±8	±8
Stem Length	90	90	100	110	120	120
Top Tube	522	532	546	556	568	583
Trail	63	63	63	63	63	63
Wheelbase	983	995	997	1008	1022	1036
