Panoramica tecnica
Telaio
Telaio:
Sportelite 24 | Al-13 butted aluminum
Forcella:
Al-13 butted aluminum
Cockpit
Piega:
BMC Junior | 560mm
Attacco Manubrio:
BMC Junior | 60mm
Reggisella:
BMC Junior | 27.2mm
Sella:
Junior
Gruppo
Ingranaggi:
3 x 7
Guarnitura:
Suntour CW14-XC | 42-34-24T (160mm)
Cassetta:
Shimano Tourney | 14-28T
Catena:
KMC Z-51
Deragliatore Anteriore:
Shimano FD-M190
Deragliatore Posteriore:
Shimano Acera
Comandi:
Shimano Tourney Revoshift
Freni
Leve Freno / Pinze:
Tektro Alloy V-brake
Ruote
Cerchi:
Alex Z-1000 32h
Mozzi:
Joytech Alloy
Pneumatici:
Kenda 2.10
| Size | 24 |
|---|---|
| Rider Height | 120-150 |
| Reach | 357 |
| Stack | 476 |
| Bar Drop | |
| Bar Reach | |
| Bar Rise | 10 |
| Bar Sweep | 6 |
| Bar Width | 560 |
| Base Bar Drop Flat Cockpit | |
| Base Bar Drop V-Cockpit | |
| Base Bar Reach Flat Cockpit | |
| Base Bar Reach V-Cockpit | |
| BB Drop | 20 |
| BB Drop (SLACK) | |
| BB Drop (STEEP) | |
| BB Height (SLACK) | |
| BB Height (STEEP) | |
| Chainstay | |
| Crank Length | 160 |
| LT | BB Drop (SLACK) | |
| LT | BB Drop (STEEP) | |
| LT | BB Height (SLACK) | |
| LT | BB Height (STEEP) | |
| LT | Chainstay | |
| LT | Fork Length | |
| LT | Fork Rake | |
| LT | Frame Size | |
| LT | Front Center (SLACK) | |
| LT | Front Center (STEEP) | |
| LT | Head Tube | |
| LT | HT Angle (SLACK) | |
| LT | HT Angle (STEEP) | |
| LT | Reach (SLACK) | |
| LT | Reach (STEEP) | |
| LT | Rider Height | |
| LT | Seat Tube | |
| LT | ST Angle @750mm Saddle Height (SLACK) | |
| LT | ST Angle @750mm Saddle Height (STEEP) | |
| LT | ST Angle Actual (SLACK) | |
| LT | ST Angle Actual (STEEP) | |
| LT | ST Angle Effective (SLACK) | |
| LT | ST Angle Effective (STEEP) | |
| LT | Stack (SLACK) | |
| LT | Stack (STEEP) | |
| LT | Stand Over Height (80 in Front of BB) | |
| LT | Stand Over Height (Lowest Point) | |
| LT | Top Tube (SLACK) | |
| LT | Top Tube (STEEP) | |
| LT | Wheelbase (SLACK) | |
| LT | Wheelbase (STEEP) | |
| ST | BB Drop (SLACK) | |
| ST | BB Drop (STEEP) | |
| ST | BB Height (STACK) | |
| ST | BB Height (STEEP) | |
| ST | Chainstay | |
| ST | Fork Length | |
| ST | Fork Rake | |
| ST | Frame Size | |
| ST | Front Center (SLACK) | |
| ST | Front Center (STEEP) | |
| ST | Head Tube | |
| ST | HT Angle (SLACK) | |
| ST | HT Angle (STEEP) | |
| ST | Reach (SLACK) | |
| ST | Reach (STEEP) | |
| ST | Rider Height | |
| ST | Seat Tube | |
| ST | ST Angle @750mm Saddle Height (SLACK) | |
| ST | ST Angle @750mm Saddle Height (STEEP) | |
| ST | ST Angle Actual (SLACK) | |
| ST | ST Angle Actual (STEEP) | |
| ST | ST Angle Effective (SLACK) | |
| ST | ST Angle Effective (STEEP) | |
| ST | Stack (SLACK) | |
| ST | Stack (STEEP) | |
| ST | Stand Over Height (80 in Front of BB) | |
| ST | Stand Over Height (Lowest Point) | |
| ST | Top Tube (SLACK) | |
| ST | Top Tube (STEEP) | |
| ST | Wheelbase (SLACK) | |
| ST | Wheelbase (STEEP) | |
| Fork Length | 399 |
| Fork Rake | 42 |
| Frame Size | |
| Front Center | 562 |
| Front Center (SLACK) | |
| Front Center (STEEP) | |
| Head Tube | 100 |
| Head Tube Angle | 71 |
| HT Angle (SLACK) | |
| HT Angle (STEEP) | |
| Pad Reach Flat Cockpit | |
| Pad Reach V-Cockpit | |
| Pad Stack Flat Cockpit | |
| Pad Stack V-Cockpit | |
| Reach (SLACK) | |
| Reach (STEEP) | |
| Rear Center | 410 |
| Saddle Height Range | |
| Seat Angle | 72 |
| Seat Tube | 320 |
| Seatpost Drop | |
| Seatpost Length | 250 |
| Seatpost Offset | 15 |
| ST Angle @750mm Saddle Height (SLACK) | |
| ST Angle @750mm Saddle Height (STEEP) | |
| ST Angle Actual (SLACK) | |
| ST Angle Actual (STEEP) | |
| ST Angle Effective (SLACK) | |
| ST Angle Effective (STEEP) | |
| Stack (SLACK) | |
| Stack (STEEP) | |
| Stand Over Height (80 in Front of BB) | |
| Stand Over Height (Lowest Point) | |
| Standover Height | |
| Stem Angle | 15 |
| Stem Length | 60 |
| Top Tube | 515 |
| Top Tube (SLACK) | |
| Top Tube (STEEP) | |
| Trail | 59 |
| Wheelbase | 971 |
| Wheelbase (SLACK) | |
| Wheelbase (STEEP) |
