Panoramica tecnica

Telaio

Telaio:
Fourstroke 01 - Advanced Pivot System - Race Application Dropper - PF92 Bottom Bracket - 12 x 148mm Thru-axle - 100mm Travel | 01 Premium Carbon (F&R)

Forcella:
01 Premium Carbon (F&R)

Cockpit

Piega:
BMC MFB 01 Carbon | 750mm

Attacco Manubrio:
BMC MSM 01

Reggisella:
BMC RAD 80mm Drop

Sella:
Fizik Antares R7

Seat

Seatpost:
BMC RAD 80mm Drop

Saddle:
Fizik Antares R7

Gruppo

Ingranaggi:
1 x 12

Guarnitura:
Truvativ Stylo Carbon | 34T

Cassetta:
SRAM GX Eagle | 10-50T

Catena:
SRAM GX Eagle

Deragliatore Posteriore:
SRAM XX1 Eagle

Comandi:
SRAM GX Eagle

Freni

Leve Freno / Pinze:
SRAM Level TLM (160/160) *

Ruote

Cerchi:
DT Swiss XR1501 Spline 25 **

Mozzi:
DT Swiss XR1501 Spline

Pneumatici:
Vittoria Barzo G2,0 tubeless 2.25

Size	S	M	L	XL
Rider Height	<172	172-182	180-188	>188
Reach	423	445	465	485
Stack	580	590	600	615
Bar Drop
Bar Reach
Bar Rise
Bar Sweep	9	9	9	9
Bar Width	720	720	720	720
Base Bar Drop Flat Cockpit
Base Bar Drop V-Cockpit
Base Bar Reach Flat Cockpit
Base Bar Reach V-Cockpit
BB Drop	44	44	44	44
BB Drop (SLACK)
BB Drop (STEEP)
BB Height (SLACK)
BB Height (STEEP)
Chainstay
Crank Length	170	175	175	175
LT \| BB Drop (SLACK)
LT \| BB Drop (STEEP)
LT \| BB Height (SLACK)
LT \| BB Height (STEEP)
LT \| Chainstay
LT \| Fork Length
LT \| Fork Rake
LT \| Frame Size
LT \| Front Center (SLACK)
LT \| Front Center (STEEP)
LT \| Head Tube
LT \| HT Angle (SLACK)
LT \| HT Angle (STEEP)
LT \| Reach (SLACK)
LT \| Reach (STEEP)
LT \| Rider Height
LT \| Seat Tube
LT \| ST Angle @750mm Saddle Height (SLACK)
LT \| ST Angle @750mm Saddle Height (STEEP)
LT \| ST Angle Actual (SLACK)
LT \| ST Angle Actual (STEEP)
LT \| ST Angle Effective (SLACK)
LT \| ST Angle Effective (STEEP)
LT \| Stack (SLACK)
LT \| Stack (STEEP)
LT \| Stand Over Height (80 in Front of BB)
LT \| Stand Over Height (Lowest Point)
LT \| Top Tube (SLACK)
LT \| Top Tube (STEEP)
LT \| Wheelbase (SLACK)
LT \| Wheelbase (STEEP)
ST \| BB Drop (SLACK)
ST \| BB Drop (STEEP)
ST \| BB Height (STACK)
ST \| BB Height (STEEP)
ST \| Chainstay
ST \| Fork Length
ST \| Fork Rake
ST \| Frame Size
ST \| Front Center (SLACK)
ST \| Front Center (STEEP)
ST \| Head Tube
ST \| HT Angle (SLACK)
ST \| HT Angle (STEEP)
ST \| Reach (SLACK)
ST \| Reach (STEEP)
ST \| Rider Height
ST \| Seat Tube
ST \| ST Angle @750mm Saddle Height (SLACK)
ST \| ST Angle @750mm Saddle Height (STEEP)
ST \| ST Angle Actual (SLACK)
ST \| ST Angle Actual (STEEP)
ST \| ST Angle Effective (SLACK)
ST \| ST Angle Effective (STEEP)
ST \| Stack (SLACK)
ST \| Stack (STEEP)
ST \| Stand Over HeightÂ (80 in Front of BB)
ST \| Stand Over HeightÂ (Lowest Point)
ST \| Top Tube (SLACK)
ST \| Top Tube (STEEP)
ST \| Wheelbase (SLACK)
ST \| Wheelbase (STEEP)
Fork Length	506	506	506	506
Fork Rake	44	44	44	44
Frame Size
Front Center	700	726	750	777
Front Center (SLACK)
Front Center (STEEP)
Head Tube	96	107	117	134
Head Tube Angle	67.5	67.5	67.5	67.5
HT Angle (SLACK)
HT Angle (STEEP)
Pad Reach Flat Cockpit
Pad Reach V-Cockpit
Pad Stack Flat Cockpit
Pad Stack V-Cockpit
Reach (SLACK)
Reach (STEEP)
Rear Center
Saddle Height Range
Seat Angle	75.6	75.6	75.6	75.6
Seat Tube	420	440	480	510
Seatpost Drop
Seatpost Length	105	105	105	105
Seatpost Offset
ST Angle @750mm Saddle Height (SLACK)
ST Angle @750mm Saddle Height (STEEP)
ST Angle Actual (SLACK)
ST Angle Actual (STEEP)
ST Angle Effective (SLACK)
ST Angle Effective (STEEP)
Stack (SLACK)
Stack (STEEP)
Stand Over Height (80 in Front of BB)
Stand Over Height (Lowest Point)
Standover Height
Stem Angle	-5	-5	-5	-5
Stem Length	50	60	60	70
Top Tube	582	607	630	654
Top Tube (SLACK)
Top Tube (STEEP)
Trail	106.5	106.5	106.5	106.5
Wheelbase	1129	1155	1180	1206
Wheelbase (SLACK)
Wheelbase (STEEP)
