Name: Trailfox 03 X1
Brand: BMC
SKU: BMC-16a-000096-s0050
Availability: OutOfStock

Trailfox 03 X1 | BMC | bikes | Mountain, Mountain | Trail

RED

BMC Archive Product

Piezas y accesorios compatibles

Axle / Nut

CAD 138.00 Ver producto

Dropout - No 44

CAD 34.00 Ver producto

[{"id":47384605950272,"title":"S","option1":"S","option2":null,"option3":null,"sku":"BMC-16a-000096-s0050","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Trailfox 03 X1 - S","public_title":"S","options":["S"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":47384606507328,"title":"M","option1":"M","option2":null,"option3":null,"sku":"BMC-16a-000096-s0070","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Trailfox 03 X1 - M","public_title":"M","options":["M"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":47384606998848,"title":"L","option1":"L","option2":null,"option3":null,"sku":"BMC-16a-000096-s0090","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Trailfox 03 X1 - L","public_title":"L","options":["L"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

Descripción técnica

Cuadro

Cuadro:
Trailfox 03 29 - Advanced Pivot System | Al-13 Premium Triple-butted aluminum (F&R)

Horquilla:
Al-13 Premium Triple-butted aluminum (F&R)

Cockpit

Manillar:
BMC MFB 02 | 750mm

Potencia:
BMC AMSM 02 | 45mm

Tija de Sillín:
Fast Ace Dropper (125mm)

Sillín:
Fizik Nisene XS

Transmisión

Marchas:
1 x 11

Platos y Bielas:
SRAM X1 | 30T

Cassette:
SRAM PG1150 | 10-42T

Cadena:
KMC X-11L EPT

Cambio Trasero:
SRAM X1

Manetas de Cambio:
SRAM GX-11

Frenos

Pinzas de Freno:
Shimano SLX 203/203mm

Ruedas

Llantas:
DT Swiss E512

Bujes:
SRAM MTH-716 (F) / MTH-746 (R)

Neumáticos:
Onza: Ibe x FRC120 (F) / Ibe x FRC60 (R) | 2.4

Información adicional

Reglamento relativo a la seguridad general de los productos (GPSR):
Instrucciones de seguridad GPSR (UE)
Persona responsable según el GPSR (UE)

Size	S	M	L
Reach	410	435	460
Stack	610	615	619
Bar Rise	4	4	4
Bar Sweep	9	9	9
Bar Width	750	750	750
BB Drop	30	30	30
Crank Length	170	175	175
Fork Length	562	562	562
Fork Rake	51	51	51
Front Center	712	739	766
Head Tube	90	95	100
Head Tube Angle	67	67	67
Rear Center	438	435	435
Seat Angle	74	74	74
Seat Tube	400	440	480
Seatpost Length	350	400	400
Stem Angle	6	6	6
Stem Length	55	55	55
Top Tube	585	611	638
Trail	101	101	101
Wheelbase	1145	1173	1200
