Name: Kaius 01 ONE
Brand: BMC
SKU: 30005792
Price: 16799.0 CAD
Availability: OutOfStock

Peacock Spider

New SRAM RED XPLR AXS 1x13 Drivetrain
GC 39 SL Carbon Wheelset
ICS Carbon Aero One-Piece Cockpit

CAD 16,799.00

SKU: 30005792

Size —

Compatible Parts & Accessories

Shipped to your local bike shop

Check for availability within our Retailer Network.

[{"id":47342753153344,"title":"47","option1":"47","option2":null,"option3":null,"sku":"30005791","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Kaius 01 ONE - 47","public_title":"47","options":["47"],"price":1679900,"weight":15000,"compare_at_price":0,"inventory_management":"shopify","barcode":"7630906512166","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":47342753612096,"title":"51","option1":"51","option2":null,"option3":null,"sku":"30005792","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Kaius 01 ONE - 51","public_title":"51","options":["51"],"price":1679900,"weight":15000,"compare_at_price":0,"inventory_management":"shopify","barcode":"7630906512159","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":47342754300224,"title":"54","option1":"54","option2":null,"option3":null,"sku":"30005793","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Kaius 01 ONE - 54","public_title":"54","options":["54"],"price":1679900,"weight":15000,"compare_at_price":0,"inventory_management":"shopify","barcode":"7630906512142","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":47342754857280,"title":"56","option1":"56","option2":null,"option3":null,"sku":"30005794","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Kaius 01 ONE - 56","public_title":"56","options":["56"],"price":1679900,"weight":15000,"compare_at_price":0,"inventory_management":"shopify","barcode":"7630906512135","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":47342755348800,"title":"58","option1":"58","option2":null,"option3":null,"sku":"30005795","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Kaius 01 ONE - 58","public_title":"58","options":["58"],"price":1679900,"weight":15000,"compare_at_price":0,"inventory_management":"shopify","barcode":"7630906512128","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":47342755840320,"title":"61","option1":"61","option2":null,"option3":null,"sku":"30005796","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Kaius 01 ONE - 61","public_title":"61","options":["61"],"price":1679900,"weight":15000,"compare_at_price":0,"inventory_management":"shopify","barcode":"7630906512111","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

Kaius is a premium carbon gravel bike built to be your elite race companion for all terrains. The unprecedented carbon layup and gravel-specific geometry ensure the perfect balance of stiffness, lightweight, and compliance for optimal traction on loose surfaces, front-end stability, and unmatched climbing prowess. Harnessing the precision and performance of our renowned leading road technologies, Kaius is a race machine tuned to the gravel wavelength with the engineered Kaius fork, our ICS Carbon Aero Cockpit, TCC Race compliance, the new 13-speed SRAM RED XPLR AXS drivetrain and up to 44 mm of tire clearance.

Technology

Speed Unbound

The innovative premium carbon layup uses ultra high-module fibres for unmatched stiffness resulting in maximum power transfer and minimal weight. Kaius boasts our Tuned Compliance Concept Race Technology for a comfortable ride on rough surfaces.

Race-ready Gravel Geometry

Kaius was built with one purpose: to be fast on gravel roads. That is why we produced a gravel-specific frame with a longer reach shifting the front wheel forward to improve stability and increase traction on loose surfaces.

ICS Carbon Aero Cockpit

The ICS Carbon Aero Cockpit, with its progressive and aerodynamic shape, is the perfect match for this bike. Featuring a narrow top width, allowing an efficient aero position with a greater width at the drops providing incredible control at high speed.

Aerocore Design

Kaius comes in at the highest level of functional integration with our Aerocore design. This evolved solution integrates the bottle cages into the frame to optimize aerodynamic performance.

Technical Overview

Frameset

Cockpit

Handlebar:
ICS Carbon Aero | One-Piece Full Carbon Cockpit

Seat

Seatpost:
Kaius 01 Premium Carbon D-Shaped Seatpost | 15mm Offset | D-Fender Compatible

Saddle:
Fizik Vento Argo R1 | 140mm

Drivetrain

Crankset:
SRAM RED XPLR AXS DUB WIDE E1

Chainrings:
42T

Power Meter:
SRAM Red AXS Power Meter (FC-RED-P-E1)

Cassette:
SRAM RED XPLR (XG-1391-E1)

Cassette Size:
10-46T

Chain:
SRAM RED (CN-RED-E1)

Rear Derailleur:
SRAM RED XPLR AXS (RD-RED-1E-E1)

Shifters:
SRAM RED AXS (ED-RED-E1)

Gears:
1 x 13

Bottom Bracket:
SRAM Press Fit DUB

Brakes

Brake Levers / Calipers:
SRAM RED AXS (ED-RED-E1)

Rotors:
SRAM Paceline X | Centerlock

Rotor Size (F/R):
160 / 160mm

Wheels

Rims:
CG 39 SL Carbon | Tubeless Ready | 39mm

Hubs (F/R):
CG 39 SL for Carbon Spokes | Star Ratchet Freehub

Tires:
Pirelli Cinturato Gravel H | 40mm

Tubeless Information:
Tubeless Ready Rims | Tubetype Tires

Accessories

Aerocore Bottle Cages

Size	47	51	54	56	58	61
Rider Height	<166	166-174	172-180	178-186	184-192	>190
Reach	390	397	401	405	410	414
Stack	510	530	550	570	595	620
Bar Drop	69	69	69	69	69	69
Bar Reach	72.5	72.5	72.5	72.5	72.5	72.5
Bar Width	360/420	360/420	360/420	360/420	360/420	360/420
BB Drop	80	80	80	80	80	80
Crank Length	170	170	172.5	172.5	175	175
Fork Length	387	387	387	387	387	387
Fork Rake	50	50	45	45	45	45
Front Center	596	610	608	619	632	644
Head Tube	85	106	123	144	170	196
Head Tube Angle	71	71	72	72	72	72
Rear Center	420	420	420	420	420	420
Seat Angle	73	73	73	73	73	73
Seat Tube	428	452	468	493	513	533
Seatpost Length	280	320	360	360	402	400
Seatpost Offset	15	15	15	15	15	15
Standover Height	684	722	756	780	798	818
Stem Angle	-15	-15	-15	-15	-15	-15
Stem Length	80	90	90	100	100	110
Top Tube	546	559	569	579	592	604
Trail	68	68	68	68	68	68
Wheelbase	1003	1017	1015	1026	1039	1051
