Technology
Technical Overview
Frameset
Frame:
Teammachine R 01 Premium Carbon with Aerocore Design | ICS Technology Stealth Cable Routing | Stealth Dropout Design | Flat Mount Disc | 12 x 142mm Thru-Axle
Fork:
Teammachine R 01 Premium Carbon | ICS Technology Stealth Cable Routing | Stealth Dropout Design | Flat Mount Disc | 12 x 100mm Thru-Axle
Cockpit
Handlebar:
BMC ICS Carbon Aero | One-Piece Full Carbon Cockpitr
Seat
Seatpost:
Teammachine R 01 Premium Carbon Seatpost | 10mm Offset
Saddle:
Fizik Argo Vento R1 | 140mm
Drivetrain
Crankset:
SRAM RED AXS
Chainrings:
48-35T
Power Meter:
SRAM RED AXS Power Meter
Cassette:
SRAM RED (XG-1290)
Cassette Size:
10-30T
Chain:
SRAM RED
Front Derailleur:
SRAM RED AXS
Rear Derailleur:
SRAM RED AXS
Shifters:
SRAM RED AXS (ED-RED-E1)
Gears:
2 x 12
Bottom Bracket:
PF86 Bottom Bracket
Brakes
Brake Levers / Calipers:
SRAM RED AXS (ED-RED-E1)
Rotors:
SRAM Paceline X | Centerlock
Rotor Size (F/R):
160 / 160mm
Wheels
Rims:
DT Swiss ARC 1100 | 62mm
Hubs (F/R):
DT Swiss 180 Straightpull | Ratchet EXP 36 | SINC Ceramic Bearings
Tires:
Pirelli P-Zero Race SL TLR | 26mm
Tubeless Information:
Tubeless Ready Rims | Tubeless Ready Tires
Accessories
Additional Information
Tire Clearance:
30mm
Weight without Pedals:
7.0 Kg
ASTM Classification:
Level 1
System Weight Limit:
110kg
Size | 47 | 51 | 54 | 56 | 58 | 61 |
---|---|---|---|---|---|---|
Rider Height | <166 | 166-174 | 172-180 | 178-186 | 184-192 | >190 |
Reach | 368 | 378 | 387 | 393 | 402 | 409 |
Stack | 504 | 528 | 548 | 563 | 582 | 608 |
Bar Reach | 72.5 | 72.5 | 72.5 | 72.5 | 72.5 | 72.5 |
Bar Width | 360/420 | 360/420 | 360/420 | 360/420 | 360/420 | 360/420 |
BB Drop | 69 | 69 | 69 | 69 | 69 | 69 |
Crank Length | 170 | 170 | 172.5 | 172.5 | 175 | 175 |
Fork Length | 367 | 367 | 367 | 367 | 367 | 367 |
Fork Rake | 48 | 48 | 43 | 43 | 43 | 43 |
Front Center | 568 | 586 | 589 | 599 | 614 | 630 |
Head Tube | 108 | 133 | 149 | 165 | 185 | 211 |
Head Tube Angle | 71.5 | 71.5 | 72.3 | 72.3 | 72.3 | 72.3 |
Rear Center | 410 | 410 | 410 | 410 | 410 | 410 |
Seat Angle | 74 | 74 | 73.5 | 73.5 | 73 | 73 |
Seat Tube | 418 | 463 | 499 | 519 | 541 | 570 |
Seatpost Length | 335 | 335 | 385 | 385 | 405 | 405 |
Seatpost Offset | 10 | 10 | 10 | 10 | 10 | 10 |
Stem Angle | -15 | -15 | -15 | -15 | -15 | -15 |
Stem Length | 90 | 100 | 100 | 110 | 110 | 120 |
Top Tube | 522 | 532 | 552 | 562 | 582 | 598 |
Trail | 63 | 63 | 63 | 63 | 63 | 63 |
Wheelbase | 968 | 986 | 989 | 999 | 1015 | 1030 |
