Name: Trackmachine 01 FRS
Brand: BMC
SKU: 30001487
Price: 5039.0 CAD
Availability: OutOfStock

Trackmachine 01 FRS | BMC | frames | Track, Track | Racing

Carbon / White

BMC Archive Product

Compatible Parts & Accessories

Axle Adjuster - No 3

CAD 34.00 View Product

Dropout - No 46

CAD 54.00 View Product

Headset TM01

CAD 82.00 View Product

Seatpost Clamp - No 13

CAD 20.00 View Product

TR01 Fork Bumpers

CAD 20.00 View Product

TR01 Seatpost

CAD 82.00 View Product

TR01 Steerer tube large

CAD 54.00 View Product

TR01 Stem Cover

CAD 20.00 View Product

TR01 Stem Kit

CAD 348.00 View Product

[{"id":47358207754560,"title":"S","option1":"S","option2":null,"option3":null,"sku":"30001487","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Trackmachine 01 FRS - S","public_title":"S","options":["S"],"price":503900,"weight":8000,"compare_at_price":629900,"inventory_management":"shopify","barcode":"7630027872477","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":47358207787328,"title":"M","option1":"M","option2":null,"option3":null,"sku":"30001488","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Trackmachine 01 FRS - M","public_title":"M","options":["M"],"price":503900,"weight":8000,"compare_at_price":629900,"inventory_management":"shopify","barcode":"7630027872569","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":47358207852864,"title":"L","option1":"L","option2":null,"option3":null,"sku":"30001489","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Trackmachine 01 FRS - L","public_title":"L","options":["L"],"price":503900,"weight":8000,"compare_at_price":629900,"inventory_management":"shopify","barcode":"7630027872552","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

Technical Overview

Frameset

Frame:
Trackmachine 01 Premium Carbon with Vmax Aero Design P2P Positioning System | Sliding Dropouts

Fork:
Trackmachine 01 Premium Carbon with Vmax Aero Design Hinge-Design

Cockpit

Stem:
Vmax Aero Integrated Design | P2P Technology

Seat

Seatpost:
Trackmachine 01 Premium Carbon Aero Seatpost with P2P Positioning SyStem

Brakes

Brake Levers / Calipers:

Rotors:

Rotor Size (F/R):

Wheels

Rims:

Hubs (F/R):

Tires:

Tubeless Information:

Additional Information

Tire Clearance:
23mm

ASTM Classification:
Level 1

System Weight Limit:
150kg

General Product Safety Regulation (GPSR):
Safety Instructions GPSR (EU)
Responsible person according to GPSR (EU)

Size	S	M	L
Rider Height	<173	170-185	>183
Reach	390	408	430
Stack	471	506	544
BB Drop	50	58	58
Fork Length	363	363	363
Fork Rake	48	48	48
Front Center	586	604	626
Head Tube	94	134	163
Head Tube Angle	72	72	72
Rear Center	390-420	390-420	390-420
Seat Angle	74	74	74
Seat Tube	505	542	582
Seatpost Length	300	300	300
Seatpost Offset	30 / 10 / -10 / -30	30 / 10 / -10 / -30	30 / 10 / -10 / -30
Standover Height	751	779	817
Top Tube	525	553	585
Trail	59	59	59
Wheelbase	963	981	1003
